Product Details:
|
Item: | Horizontal Ball Mill | Type: | Horizontal |
---|---|---|---|
Mill Jars: | 4*1.5L | Usage: | Ultra-fine Powder Grinding |
Highlight: | 6L Laboratory Ball Mill Machine,70rpm Laboratory Ball Mill Machine,Fine Powder horizontal ball mill |
6L Horizontal laboratory ball mill 4*1.5L Mill Jars For Ultra-fine Powder Grinding Without Dead Corner
Overview
Planetary ball mills may be used for mixing, homogenizing, fine grinding, mechanical alloying, cell disruption, small volume high-tech material production and even colloidal grinding. They are the ideal wet/dry milling tools for acquiring research samples with high efficiency and low noise. Vacuum jars may be used to process sample within a vacuum environment.
Working Principle
Planetary ball mills have four grinding stations arranged on the "Sun Wheel" of the planetary ball mill. When the Sun Wheel rotates, the grinding balls inside the jars are subject to superimposed rotational movements, known as Coriolis Forces. The difference in speeds between the grinding balls and jars produce an interaction between frictional and impact forces, which release high dynamic energies. Minimum granularity of the final product can be as small as 0.1 micron.
Applications
Horizontal laboratory ball mill is widely applied in industries such as geology, mineral, metallurgy, electronics, building materials, ceramics, chemical industry, light industry, medicine, environmental protection and so on.
Product Display
Advantages
1. High uniformity and excellent repeatability.
2. Fast rotational speed, high efficiency and fine granularity.
3. Four samples with different sizes and materials in one experiment.
4. The machine is controlled by frequency converter; you may choose ideal rotating speed according to expected experimental result. The converter is equipped with device of under voltage and over-current to protect the motor.
5. The planetary ball mill has functions of timing power off, self-timing forward and reversal rotating. You may choose freely any operation modes of one-way direction, alternation, succession, and timing according to experimental needs so as to improve efficiency of grinding.
6. Low center of gravity, stable performance, compact structure, easy operation, reliable safety, lower noise, small loss.
7. Safety switch is installed on the machine to prevent safety accident if the safety cover is opened while machine is running.
Technical Features
Drive Mode | Gear drive |
Operation Mode | Two or four grinding tanks working together |
Maximum Loading Capacity | 2/3 of the capacity of milling tank |
Feeding Size | Soil material≤10mm, other materials≤3mm |
Output Granularity | Smallest granule reaches 0.1 μm |
Rotational Speed Ratio | 1/2 |
Max. Continuous Operating Time | 72hours |
Optional Modes of Speed Control | Frequency conveter and automatic timing control |
Materials of Jar | Stainless steel, agate, nylon, corundum, zirconia, etc. |
Technical Parameters
Model No. | Power (kw) |
Voltage (v) |
Dimension (mm) |
Revolution Speed (rpm) |
RotationSpeed (rpm) |
Total Timing (min) |
Alternating Run Time of Forward & Reversal Rotation (min) |
YQHM-0.4L | 0.75 | 220V-50Hz | 700*510*570 | 35-335 | 70-670 | 1-9999 | 1-999 |
YQHM-1L | 0.75 | 220V-50Hz | 700*510*570 | 35-335 | 70-670 | 1-9999 | 1-999 |
YQHM-2L | 0.75 | 220V-50Hz | 700*510*570 | 35-335 | 70-670 | 1-9999 | 1-999 |
YQHM-4L | 0.75 | 220V-50Hz | 700*510*570 | 35-335 | 70-670 | 1-9999 | 1-999 |
YQHM-6L | 0.75 | 220V-50Hz | 700*510*570 | 35-335 | 70-670 | 1-9999 | 1-999 |
Available Mill Jars:
304 stainless steel mill jar, 316 stainless steel mill jar, tungsten carbide mill jar, agate mill jar, alumina ceramic mill jar(also called corundum mill jar), zirconia mill jar, nylon mill jar, polyurethane mill jar, Teflon mill jar (PTFE), and etc.
