Product Details:
|
Product Name: | Lab Agate Ball Mill Jar / Agate Grinding Jar With Lid Made In China | Material: | Agate |
---|---|---|---|
Volume: | 100ml/250ml/500ml/1L/2L/5L | Usage: | Used For Ball Mill Machine |
Highlight: | 1L Ball Mill Jars,ceramic Ball Mill Jars,130mm ceramic mill jar |
Lab Agate Ball Mill Jar / Agate Grinding Jar With Lid Made In China
Product Introduction
Agate mill jar: no impurities, no cracks, glossy, high-quality, strong vibration resistance. After experiments, it shows that the item have no cracks, no bump after high-speed vibration abrasion.
Product Parameters
Volume of Jar |
Outside Diameter (mm) |
Inner Diameter (mm) |
Inner Depth (mm) |
Height of Jar (Not Contain Cover (mm) | Total Height (mm) | Weight (KG) |
50ml | 65 | 45 | 37 | 49 | 57 | 0.36 |
100ml | 75 | 50 | 52 | 62 | 70 | 0.56 |
250ml | 94 | 73 | 70 | 80 | 90 | 0.84 |
500ml | 106 | 82 | 90 | 100 | 108 | 1.31 |
1L | 130 | 107 | 114 | 126 | 141 | 2.54 |
2L | 156 | 130 | 150 | 170 | 190 | 4.43 |
Product Display
Features
1. The specific weight is huge, high strength, high grinding efficiency, shorten
the processing time.
2. True sphericity is high, smooth surface, the diameter distribution is small, can be crushing and dispersion of high-precision products.
3. Can be minimized to limit the incorporation of impurities due to the use of high purity natural agate raw material, it has a purity.
4. Good wear resistance, long life,there is no need to frequent supplement agate grinding balls, reduce production costs.
5. Could also play a large power to wet grinding and dispersion of pulverized material that viscous and than the major.
