Product Details:
|
| Product Name: | Factory Outlet Constant Temperature Type Full-automatic Rotary Agitator For TCLP Testing | Material: | Overall Steel Structure With Anti-corrosion Coating |
|---|---|---|---|
| Adapted Container: | 2L PE/ Glass / PTFE Bottle, Pollutant Extractor | Rotate Speed: | 0-60RPM ±1R/MIN |
| Temperature: | ROOM TEMP - 60℃ | Application: | Liquid With Suspended Solids, Chemicals Processing, TCLP |
| Voltage: | 220V/110V | Warranty: | 1 Year |
Product Introduction
Automatic Rotary Agitators(Cabinet Type) are sample agitation devices developed for use during the Extraction Procedure, Toxicity Characteristic Leaching Procedure (TCLP) US EPA Method 1311 and the Synthetic Precipitation Leaching Procedure (SPL).
Applications
Widely applied in the related industry of solid waste toxicity identification, sample research treatment in industry of environment protection & solid waste dispose.
Product Specification
| Vessels loaded | 6 / 8 / 12 pcs 2L bottles (1L bottle available if needed) |
| Bottle type | PE Bottle / PTFE Bottle / Glass Bottle / Zero Headspace Extractor for choose |
| Time Set | Minute/Hour set, 1-24H for alternative, accuracy to minute |
| Rotation Method | Continuous positive rotation , Interval rotation Mode and Multi-segment curve mode settings are available. The rotation speed,rotation time and temperature can be set as per requirements. |
| Rotation Speed | 0-60 rpm adjustable, digital display, accuracy reach ±1 rpm, Default set is 30 rpm |
| Machine Material | Overall steel structure with anti-corrosion coating, and stainless steel fixtures |
| Temperature Set | Room temperature to 60℃ adjustable |
| Operation Method | Micro computer controlled, button operated, LCD panel display. |
| Safety Device | With flip cover electricity insulation device, electricity leakage protection device & overload protection device |
| Alternative Accessories | Extraction container, high pressure filter system, extraction liquor collector, extraction agent, micro hole filter screen, etc |
| Standard Configuration | constant temperature system, temperature control accuracy±0.5℃ |
Product Display
Product Parameters
| Model | Bottle Qty | Bottle Volume | Rotation Speed | Power Supply | Temperature | Dimension |
| YKZ-06IV-H | 6pcs | 2L | 0-60RPM ±1R/MIN | AC 220V | Room TEMP - 60℃ | 1050*520*1575MM |
| YKZ-08IV-H | 8pcs | 2L | 0-60RPM ±1R/MIN | AC 220V | Room TEMP - 60℃ | 1050*520*1575MM |
| YKZ-12IV-H | 12pcs | 2L | 0-60RPM ±1R/MIN | AC 220V | Room TEMP - 60℃ | 1050*520*1575MM |
Product Advantages
